Remote control survey boat HYS-15

It can be used in the river basin to carry
a single beam depth sounder to achieve unmanned underwater terrain measurement.

It can be used in the river basin to carry
a single beam depth sounder to achieve unmanned underwater terrain measurement.

First, technical parameters

1. Hull:

(1) Hull shape: Three-body streamline ship
type, the hull has a stable driving posture, has anti-rollover setting, and the
compartment is closed. The boat cover is waterproof and sealed to ensure that
the cabin does not enter the water;

(2) Hull material: high-strength FRP
material with carbon fiber and Kevlar bulletproof cloth material, with
waterproof, anti-collision and anti-wear devices;

(3) Hull size: 1.50 m (length) × 0.70 m
(width) × 0.36 m (height). Small hull, light weight, easy to carry and carry;

(4) Hull weight: 15 kg;

(5) Hull load: ≤15kg;

2. Power system:

The environmentally-friendly lithium
polymer battery is used as the main power of the ship, and the power and
propulsion system are modularized.

(1) Lithium polymer battery: 2 groups,
voltage 14.8V, capacity 21Ah,

(2) Number of battery charge and discharge:
not less than 500 times, life expectancy is not less than 90%

(3) The battery life is more than 4 hours,
charging is convenient, plug and charge.

(4) With overheat protection and charging
protection

3. Propulsion system:

(1) Hanging type, pluggable double
propeller, easy to install and maintain;

(2) Integrated design of steering gear and
thruster;

(3) The propeller has a waterproof grass
winding function;

(4) The thrust of the propeller servo is
more than 100kg;

(5) The maximum speed of the ship is 4 m /
s, and the general cruising speed is 3 m / s;

(6) thruster power 180 W;

(7) Endurance: 4 hours at a constant speed
and 2 hours at a high speed;

4. Communication system:

The vessel and the remote control adopt
wireless radio frequency point-to-point two-way communication, and the
communication distance is more than 2 kilometers;

5, smart remote control:

Remote control operation measures the boat.

The remote control screen can display the
current power of the ship, the power of the remote control, and the
communication channel;

It can display the remote hull out of
control or fault alarm.

The current maximum ship speed can be
continuously adjusted according to the water flow rate.

(1) Weight ≤ 1 kg;
waterproof and dustproof rating;

(2) IP64 (rainproof);

(3) rocker mode: resistive;

(4) Rocker range: 360 degrees;

(5) Remote control distance ≤ 2 km;

(6) battery life time 12h;

(7) Communication module: GFSK;

6, measuring equipment installation:

There are installation platforms for
measuring instruments and accessories of different models and sizes, which are
easy to install, safe and secure.

The illuminating single beam sounder can be
installed. The length of the instrument transducer is 18 cm; the maximum weight
of the instrument can be 15 kg; GPS antenna installation is supported.
