Bayonet Coupling 1C/1D

PART NO.

THREAD

TUBE O.D.

DIMENSIONS

BODY

ASSEMBLY

E

F

D1

D2

L1

I1

S1

S2

S3

1C-12-14Z

1C-12-14 RNW

M12×1.5

M14×1.5

6

8

40

11

14

14

17

1C-12-16Z

1C-12-16 RNW

M12×1.5

M16×1.5

6

10

41

12

17

14

19

1C-12-18Z

1C-12-18 RNW

M12×1.5

M18×1.5

6

12

42

13

19

14

22

1C-14-16Z

1C-14-16 RNW

M14×1.5

M16×1.5

8

10

41

12

17

17

19

1C-14-18Z

1C-14-18 RNW

M14×1.5

M18×1.5

8

12

42

13

19

17

22

1C-16-18Z

1C-16-18 RNW

M16×1.5

M18×1.5

10

12

43

14

19

19

22

1C-16-22Z

1C-16-22 RNW

M16×1.5

M22×1.5

10

15

44.5

15

24

19

27

1C-16-26Z

1C-16-26 RNW

M16×1.5

M26×1.5

10

18

46

15.5

27
